This kit provides a neat way to achieve a smooth offset handrail to a stepped or flat area for access.
The saddle bracket swivels within the Elbow fitting that sits on top of the upright to allow any angle of handrail to be achieved before fitting into the wall flange, this also swivels to suit the structure it will be fixed into.
The uprights are secured by selecting the most suitable method from our “Top Fix”, “Side Fix” or “Cast in” solutions. Where using cast in or top fix it is essential to add the extra length of material you will need above the ground for dimension A.
The wall flange is secured through the two holes in the base plate.
Our kits come with the correct fixings to suit the material you are connecting to so you have everything to secure the handrail.
Additional uprights are supplied when the handrail length B requires this.
